Sinotruk Howo TX 430 8x4 Tipper Truck

Vehicle type

Dump Trucks

Model

ZZ3317V306GF1

Dimension(mm)

10800*2550*3250

Engine

WP12.430E62

Max Horsepower

430

Transmission

HW19710, 10F & 2R

Drive type

8x4

WhatApp Message

Product Introduction

Overview

The King of Heavy Duty Transportation: the Sinotruk Howo TX 430 8×4 Tipper Truck
In the field of heavy-duty transportation, the Sinotruk Howo TX 430 8×4 Tipper Truck stands out with its power and excellent performance. Equipped with a powerful 430 horsepower engine, this Sinotruk Howo TX 430 8×4 Tipper Truck provides plenty of power for a variety of heavy-duty jobs.

The Sinotruk Howo TX 430 8×4 Tipper Truck‘s cargo box design is optimized for high loading capacity and tipping efficiency. The advanced hydraulic system makes the Sinotruk Howo TX 430 8×4 Tipper Truck smoother and faster during unloading, which greatly improves work efficiency.

From an economic point of view, the Sinotruk Howo TX 430 8×4 Tipper Truck‘s fuel consumption is well controlled and maintenance is relatively easy, enabling operators to get a better return on investment. Many logistics companies and engineering contractors choose the Sinotruk Howo TX 430 8×4 Tipper Truck as their main transportation equipment.

With its reliable quality, powerful performance and economical operating costs, the Sinotruk Howo TX 430 8×4 Tipper Truck has set the benchmark in the heavy-duty tipper market, making it the ideal choice for modern engineering and construction and material transportation.

Sinotruk Howo TX 430 8x4 Tipper Truck

The Sinotruk Howo TX 430 8×4 Tipper Truck features an 8×4 drive configuration with four drive wheels to ensure excellent traction and passing power in tough road conditions. Whether on a construction site or in a quarry, the Sinotruk Howo TX 430 8×4 Tipper Truck is capable of performing a wide range of dumping tasks in a stable and reliable manner.

Parameters

DTruck Name	Sinotruk Howo TX 430 8×4 Tipper Truck
Driving Type	LHD (RHD is optional)
Engine	Make: SINOTRUK Diesel 4-stroke direct injection diesel engine Engine model: WD615.47, Euro 2, 371 HP 6-cylinder in-line with water cooling, turbo-charging and intercooling Displacement: 9.726 L
Transmission	HW19710, 10F & 2R, with PTO
Transmission	Ratio:14.28, 10.62, 7.87, 5.88, 4.38, 3.27, 2.43, 1.80, 1.34, 1.00, 13.91(R1), 3.18(R2)
Steering	ZF power steering, modol ZF8118, hydraulic steering with power assitance
Front Axle	HF9,1×9000 KGS Steering with doubleT-cross section beam
Rear Axle	HC16, 2×16000 KGS Pressed axle housing, central single reduction with hub reduction,with differential locks between wheels and axles. Ratio:5.73
Propeller Shaft	Double universal joint propeller shaft with gear-shaped coupling flange
Chassis	Frame: Uprofile parallel ladder frame with section of 300x80x8mm,reinforced subframe all cold riveted cross members
Tyres	12.00R20, radial tyres with one spare tyre
Fuel Tank	300L
Cargo Body	780023001500 mm, 27 CBM, Floor 10mm Side 8mm
Overall Dimension	1080025503250mm

Product Advantages

Excellent Ergonomic Design

Sinotruk Howo TX 430 8x4 Tipper Truck ,All controls, instrument panels, and displays are intuitively arranged for easy access and quick information retrieval, minimizing distractions and maximizing driver focus. The pneumatically controlled steering wheel is fully adjustable for both height and angle.

High Comfort

Featuring an adjustable air suspension seat, the Sinotruk Howo TX 430 8x4 Tipper Truck offers multi-directional electric adjustment and lumbar support, allowing drivers to personalize their seating for optimal comfort. Crafted from high-quality, breathable materials, the seat effectively reduces fatigue during long drives. The thoughtfully designed rest area prioritizes driver well-being, featuring a comfortable sleeper berth to ensure a restorative rest after completing a journey, allowing drivers to recharge and prepare for the road ahead.

SINOTRUK's Exclusive High-End Power

Sinotruk Howo TX 430 8x4 Tipper Truck ,Experience more power with less fuel: Employing the most advanced BOSCH high-pressure common rail system, the ECU precisely controls the fuel injection process according to the engine’s operating state, achieving a maximum injection pressure of 1600 bar to ensure superior fuel atomization, increased engine power, and reduced fuel consumption.

Transmission - Always in the Right Gear

Sinotruk Howo TX 430 8x4 Tipper Truck ,The HW series transmission incorporates a globally advanced transmission design, employing a double countershaft main transmission coupled with a planetary gear auxiliary transmission. This results in simpler, more reliable, and more durable PTO and gear shifting operations.

Axles - Carry More, Cost Less

Sinotruk Howo TX 430 8x4 Tipper Truck -The MC series drive axles and V series steering axles are engineered based on advanced German axle technology and improved with the latest technical standards, offering higher transmission efficiency, superior heat dissipation, increased load capacity, and extended service life to accommodate various road conditions.

Product Applications

Sinotruk Howo TX 430 8x4 Tipper Truck
