Sinotruk Howo NX 6x4 Mixer Truck

Sinotruk Howo NX 6x4 Mixer Truck

Vehicle type
Mixer Trucks
Model
ZZ1257V384JB1R
Power
380HP
Engine
WP10.380E22
Stirring dynamic volume
8m³-10m³
Transmission
HW25712XACL
Drive type
6x4
Product Introduction
Overview

The star product of Heavy Duty Truck Howo NX series, Sinotruk Howo NX 6×4 Mixer Truck has become the backbone of concrete transportation field with its excellent performance. This Sinotruk Howo NX 6×4 Mixer Truck  is equipped with MC series engine of German MAN technology, with maximum power up to 400 hp, and HW19710CL transmission, which enables the truck to maintain excellent fuel economy under heavy-duty working conditions.

Sinotruk Howo NX 6×4 Mixer Truck  Core Advantage:

Mixing system: adopting 8m³ three-dimensional screw belt mixing drum to ensure the homogeneity of concrete reaches more than 98%.
Chassis design: 6×4 drive form with double-layer beam structure, the carrying capacity exceeds 16 tons.
Intelligent control: standard equipped with Beidou intelligent terminal, real-time monitoring of unloading speed and remaining square meters.

Sinotruk Howo NX 6×4 Mixer Truck  Application Scenario:
The hydraulic system adopts Italian PMP gear pumps, which reduces the energy consumption of the mixer truck by 15% per revolution, thus truly realizing the operation concept of “pulling more and running faster”.

This Sinotruk Howo NX 6×4 Mixer Truck, which complies with the National VI emission standard, has become the first choice of many mixing stations, and its modularized design reduces the maintenance cost by more than 20% compared with competitors.



Sinotruk Howo NX 6x4 Mixer Truck

Sinotruk Howo NX 6×4 Mixer Truck is especially suitable for short and medium-distance transportation in urban mixing stations, and its 2700mm+1350mm wheelbase design is perfectly adapted to the complex road conditions at construction sites.

Sinotruk Howo NX 6×4 Mixer Truck-3
Parameters
SINOTRUK HOWO NX 6X4 MIXER TRUCK
Cabin H77L cab, with one sleeper and two seats, with Air Conditioner, 2-arm windscreen wiper system with three speeds, damped adjustable driver’s seat, with heating and ventilating system, exterior sun visor, safety belts, adjustable steering wheel, air horn, with transverse stabilizer,with 4-point support fully floating suspension + shock absorber.
Engine Diesel 4-stroke direct injection diesel engine
Engine model:WP10.380E22380HP
6-cylinder in-line with water cooling, turbo-charging and intercooling
Transmission HW19710, 10F & 2R
Ratio: 14.28, 10.62, 7.87, 5.88, 4.38, 3.27, 2.43, 1.80, 1.34, 1.00, 13.91(R1), 3.18(R2)
Steering ZF power steering, model ZF8118, hydraulic steering with power assistance
Front Axle VGD95, 1×9500 KGS
Steering with double T-cross section beam
Rear Axle MCX16ZG, 2×16000 KGS
Pressed axle housing, central single reduction with hub reduction and with differential locks between wheels and axles.
Chassis Frame: U-profile parallel ladder frame with section of 300x80x8mm, and reinforced subframe all cold riveted cross members
Front suspension:9semi-elliptic leaf spring, hydraulic telescopic double-action shock absorbers and stabilizer
Rear suspension:12 leaf semi-elliptic springs, bogie spring and stabilizer
Brake Service brake: dual circuit compressed air brake
Parking brake (emergency brake): spring energy, compressed air operating on front shaft and rear wheels
Auxiliary brake: engine exhaust brake
Electrics Operating voltage: 24 V, negative grounded
Starter: 24 V, 5.4 Kw
Alternator: 3-phase, 28 V, 1500 W
Batteries: 2 x 12 V, 165 Ah
Cigar-lighter, horn, headlamps, fog lights, brake lights, indicators and reverse light
Tires 12.00R20, Radial (steel wire) Tires. 10+1 Pics.
Mixer Body Tank Body: it can as your requirements
Fuel Tank 400L
Overall Dimension 9000*2550*3950 mm
Product Advantages
sinotruk howo NX truck-6
Sinotruk howo NX
HOWO-NX with high price-quality ratio
The super high price-performance ratio of the HOWO NX series will provide you with comfort, reliability and benefits that far exceed your expectations.
sinotruk howo NX truck-1
High comfort
The HOWO - NX series cab is a cab with beautiful appearance, high safety and high comfort, jointly developed by SINOTRUK and a famous Italian design company. Four-point cab suspension, airbags, air seats, large storage space, 700mm extra-wide bed, improved ergonomics and other designs provide excellent comfort and safety.
sinotruk howo NX truck-2
Safe cabin
The rigidity and strength of the cab body meet the EU ECE R29 certification standard; the design of the wide-angle rear-view mirror and lower viewing mirror increases the field of vision by 15% and improves safety.
sinotruk howo NX truck-3
Air cushion
The air cushion helps the driver quickly find a suitable seating position; the ergonomic design of the seat belt and seat helps avoid the driver feeling suffocated due to emergency braking while driving.
sinotruk howo NX truck-4
Four-point air suspension
The four-point air suspension has good stability, shock-absorbing effect and comfort, and also has the function of tilting the cabin backward during a collision to ensure the safety of passengers.
Product Applications
Sinotruk Howo NX 6×4 Mixer Truck-3
Sinotruk Howo NX 6x4 Mixer Truck
Sinotruk Howo NX 6×4 Mixer Truck-2
Sinotruk Howo NX 6x4 Mixer Truck
Sinotruk Howo NX 6×4 Mixer Truck-1
Sinotruk Howo NX 6x4 Mixer Truck
