Sinotruk Howo 7 6x4 Dump Truck

Vehicle type

Dump Trucks

Model

ZZ3317V3567B1R

Power

380hp

Engine

WP12.400E201

Fuel Tank

300L

Transmission

Sinotruk HW19710

Drive type

6x4

WhatApp Message

Product Introduction

Overview

The Sinotruk Howo 7 6×4 Dump Truck offers two drive configurations: 8×4 and 6×4, equipped with powerful engines ranging from 290 to 420 horsepower. The Sinotruk Howo 7 6×4 Dump Truck model is ideal for large-scale projects and heavy-duty transport, with a load capacity of up to 35 tons, while the 6×4 model is more flexible, suited for medium-load transport with a capacity of up to 25 tons.

With a sturdy body, efficient gearbox, and durable suspension system, Sinotruk Howo 7 6×4 Dump Truck ensures high-performance operation in challenging environments. Compliant with Euro II emission standards, it is an ideal choice for construction sites and mining transport.

Sinotruk Howo 7 6x4 Dump Truck

The Sinotruk Howo 7 6×4 Dump Truck plays a crucial role various industries. In the construction sector, Sinotruk Howo 7 6×4 Dump Truck efficiently transports large volumes of construction materials like sand, gravel, and cement to building sites across the country. The Sinotruk Howo 7 6×4 Dump Truck robust design allows it to handle the often challenging and rugged terrains in Congo, from the bumpy roads in urban areas to the more difficult off – road conditions in rural regions.

Parameters

Brand: Howo	Strain: 7	Substrain:7
Vehicle category: Medium and heavy trucks+A3:C14	Vehicle use: Tipper, Dump Truck	Drive type: 8×4/6×4
Total mass (t):25/31	Overall mass (kg):10100/11200	Wheelbase (mm):3500/3825
Vehicle length (mm):10400/8500	Vehicle width (mm):2550	Vehicle height (mm):3350/3450
Truck Model: ZZ3317V3567B1R/ZZ3257N3847B1R
Engine: WP12.400E201 engine	Engine power (Ps):380	Emission level: Euro II
Cab: HW76 new front cab	Transmission: HW19710 gearbox + HW50 power take-off(PTO)
Frame: Double layer frame (8+8/300)	Front axle: VGD95 front axle (Drum)	Drive Axle: MCP16ZG Dual Rear Axle (Drum)
Drive axle speed ratio: 5.92/5.26	Steering gear: Bosch steering gear	Brake control system: with ABS
Bumper: High bumper (Full metal)		Fuel tank/gas cylinder: 300L fuel tank
Tyres: 12.00R20 tyres (mixed tread/20PR)
Here are the specifications for the Howo 7 Dump Truck configuration you mentioned: Type: Tipper Truck, Large Truck for road transport Cab: HW76 new front cab Engine: WP12.400E201 Transmission: HW19710 gearbox + HW50 direct-connected power take-off (PTO) Front Axle (Drum): VGD95 Rear Axle (Drum): MCP16ZG dual Frame: Double-deck (8+8/300) Suspension: Front and rear reinforced multi-leaf springs (11/11/12) Steering: Bosch steering wheel Exhaust System: Standard with ABS Bumper: High-level all-metal Seats: Main mechanical + sub-lightweight Speed Ratio: 5.92 Intake System: Engineered air intake (Oil Bath Filter) Wheels: 12.00R20 (mixed tread/20PR) Fuel Tank: 300L Optional Features: Rear towing hitch, fire extinguisher, optional reversing buzzer, optional under-vehicle start-stop switch, metal bumpers with front and rear light protectors, cold and warm air conditioning Dashboard: English and French These specifications highlight the capabilities and features of the Howo 7 Dump Truck, suitable for various road transport and heavy-duty applications.
☆Made to order: We offer customized truck specifications to suit your requirements!

Product Advantages

Sinotruk howo 7

HOWO-7: Fully Equipped to Face the Toughest Working Conditions
The HOWO-7 truck excels in challenging environments like construction sites and mines, thanks to its strength, ruggedness, and durability.
In harsh working environments, HOWO-7 is fully equipped to face the toughest working conditions.

High comfort

The HOWO 7 series cab is a cab with beautiful appearance, high safety and high comfort, jointly developed by SINOTRUK and a famous Italian design company. Four-point cab suspension, airbags, air seats, large storage space, 700mm extra-wide bed, improved ergonomics and other designs provide excellent comfort and safety.

Safe cabin

The cabin's body is constructed with a one-piece steel frame, providing robust strength, rigidity, and superior resistance to impacts and external forces. Its safety performance has been proven through stringent crash testing.

Air cushion

The air cushion helps the driver quickly find a suitable seating position; the ergonomic design of the seat belt and seat helps avoid the driver feeling suffocated due to emergency braking while driving.

Four-point air suspension

The four-point air suspension provides excellent stability, shock absorption, and comfort, and features a cabin rearward displacement function during collisions, ensuring passenger safety.

Product Applications

Sinotruk Howo 7 6x4 Dump Truck
