Sinotruk TX Mixer Truck For Sale South Africa

Vehicle type

Mixer Trucks

Model

Z1317V3267B1

Dimension(m)

1200×2.55×3.950

Maximum Speed

80km/h

Mixing dynamic volume

7.5m³

Engine

Sinotruck D10.38-40

Drive type

6x4

WhatApp Message

Product Introduction

Overview

Sinotruk TX mixer truck for sale south africa integrates the latest truck technology of German man and the solid chassis technology of SINOTRUK HOWO; it is a high-end heavy truck with high appearance, strong power, high load, high efficiency, reliability, safety and comfort.Sinotruk TX mixer truck for sale south africa cab is German man original body cab. Sinotruk TX mixer truck for sale south africa safety has passed the world’s most stringent collision laws and regulations. The thickness of steel plate is 1.2mm, which exceeds 20% of the industry. The paint surface of the cab is bright, the color matching is coordinated, and it is stable, atmospheric and responsible.

Sinotruk TX mixer truck for sale south africa adopts WABCO brake valve, Voss dynamic joint and Bosch steering machine; the side space of chassis is free, which is convenient for users to install spray system; the whole system is equipped with long-term primary filter as standard, without oil pick-up, to create ultra-high reliability and safety of the whole vehicle.

Sinotruk TX mixer truck for sale south africa

This Sinotruk TX mixer truck for sale south africa is equipped with HW gearbox: large torque, higher transmission efficiency, input torque of 1900nm, double intermediate shaft of main box and planetary gear of auxiliary box, advanced design concept, forced lubrication of main and auxiliary box, no burning of teeth, more reliable performance; equipped with 16 ton double-stage deceleration drive bridge, high bearing capacity, in response to muck operation condition (water trough), double-layer dense wheel edge The sealing structure improves the mud water resistance.

Parameters

SINOTRUK TX MIXER TRUCK FOR SALE
Cabin	TX -F cab, with one sleeper and two seats, with Air Conditioner, 2-arm windscreen wiper system with three speeds, damped adjustable driver’s seat, with heating and ventilating system, exterior sun visor, safety belts, adjustable steering wheel, air horn, with transverse stabilizer,with 4-point support fully floating suspension + shock absorber.
Engine	Diesel 4-stroke direct injection diesel engine Engine model:WD615.47, 371HP 6-cylinder in-line with water cooling, turbo-charging and intercooling
Transmission	HW19710, 10F & 2R Ratio: 14.28, 10.62, 7.87, 5.88, 4.38, 3.27, 2.43, 1.80, 1.34, 1.00, 13.91(R1), 3.18(R2)
Steering	ZF power steering, model ZF8118, hydraulic steering with power assistance
Front Axle	VGD95, 1×9500 KGS Steering with double T-cross section beam
Rear Axle	MCX16ZG, 2×16000 KGS Pressed axle housing, central single reduction with hub reduction and with differential locks between wheels and axles.
Chassis	Frame: U-profile parallel ladder frame with section of 300x80x8mm, and reinforced subframe all cold riveted cross members Front suspension:9semi-elliptic leaf spring, hydraulic telescopic double-action shock absorbers and stabilizer Rear suspension:12 leaf semi-elliptic springs, bogie spring and stabilizer
Brake	Service brake: dual circuit compressed air brake Parking brake (emergency brake): spring energy, compressed air operating on front shaft and rear wheels Auxiliary brake: engine exhaust brake
Electrics	Operating voltage: 24 V, negative grounded Starter: 24 V, 5.4 Kw Alternator: 3-phase, 28 V, 1500 W Batteries: 2 x 12 V, 165 Ah Cigar-lighter, horn, headlamps, fog lights, brake lights, indicators and reverse light
Tires	12.00R20, Radial (steel wire) Tires. 10+1 Pics.
Mixer Body	Tank Body: it can as your requirements
Fuel Tank	400L
Overall Dimension	900025503950 mm

Product Advantages

Ideal Working Environment

Sinotruk TX mixer truck for sale south africa cab is designed with the driver in mind, prioritizing comfort and convenience to enhance both work and living conditions. Every detail reflects a deep understanding of their needs.

High Comfort

Featuring an adjustable air suspension seat, the HOWO-TX offers multi-directional electric adjustment and lumbar support, allowing drivers to personalize their seating for optimal comfort. Crafted from high-quality, breathable materials, the seat effectively reduces fatigue during long drives. The thoughtfully designed rest area prioritizes driver well-being, featuring a comfortable sleeper berth to ensure a restorative rest after completing a journey, allowing drivers to recharge and prepare for the road ahead.

Transmission - Always in the Right Gear

The HW series transmission incorporates a globally advanced transmission design, employing a double countershaft main transmission coupled with a planetary gear auxiliary transmission. This results in simpler, more reliable, and more durable PTO and gear shifting operations.

SINOTRUK's Exclusive High-End Power

Experience more power with less fuel: Employing the most advanced BOSCH high-pressure common rail system, the ECU precisely controls the fuel injection process according to the engine’s operating state, achieving a maximum injection pressure of 1600 bar to ensure superior fuel atomization, increased engine power, and reduced fuel consumption.

Axles - Carry More, Cost Less

The MC series drive axles and V series steering axles are engineered based on advanced German axle technology and improved with the latest technical standards, offering higher transmission efficiency, superior heat dissipation, increased load capacity, and extended service life to accommodate various road conditions.

Product Applications

Sinotruk TX mixer truck for sale south africa

Sinotruk TX mixer truck for sale south africa
