Sinotruk Howo Light Cargo Truck

Sinotruk Howo Light Cargo Truck

Vehicle type
Light Trucks
Model
ZZ1127H4515F1
Engine
Weichai WP3NQ170E62
Horsepower
170hp
Top speed:
89km/h
Transmission
8-Speed
Drive type
4x2
Product Introduction
Overview

Sinotruk Howo Light Cargo Truck find applications in various industries and sectors due to their versatility and reliability. Sinotruk Howo Light Cargo Truck are specifically designed to handle lighter loads and navigate through urban or rural areas with ease. Here are some common applications of Sinotruk howo 4×2 light cargo truck:

Logistics and Transportation:Sinotruk Howo Light Cargo Truck find are widely used for the transportation of goods and materials in urban and suburban areas. Their compact size and maneuverability make them well-suited for navigating through congested city streets and narrow lanes.

E-commerce Delivery: With the rapid growth of e-commerce, Sinotruk Howo Light Cargo Truck find are commonly used for last-mile deliveries. Their ability to access residential areas and make frequent stops makes them ideal for delivering packages and parcels to customers’ doorsteps.

Sinotruk Howo Light Cargo Truck

Municipal Services: Sinotruk Howo 4×2 Light Cargo Truck are employed by municipal authorities for various tasks such as garbage collection, street sweeping, and maintenance of public spaces. Their agility and versatility enable efficient operations in urban environments.

sinotruk howo light cargo truck-4
Parameters
Sinotruk Howo Light Cargo Truck Specifications
Engine
Engine model: YN4102QBZL,EuroⅡemission standard
Clutch
Single-plate diaphragm spring clutch, diameter 300 mm, hydraulically operating
Transmission
WLY transmission, model WLY646,synchromesh,6 forward & 1 reverse Ratio:6.314 3.913 2.262 1.393 1 0.788 5.874 (R)
Front Axle
VGD027QB, forging forming of front axle I-beam, to guarantee the stiffness and high strength.
Rear Axle
HGC055QJ,mature punching welding axle and pressed axle housing Ratio:4.63
Chassis
Frame :ladder frame with section of 215×70×6 mm, all cold riveted cross members
Steering
LG9704470020,hydraulic steering with power assistance Ratio: 18.85:1
Brakes
Service brake: dual circuit compressed air brake Parking brake (emergency brake):spring energy, compressed air operating on rear wheels (optional) Auxiliary brake: engine exhaust brake (optional)
Wheels & Tyres
Rims: 6.00G-16,6 hole-steel Tyres:8.25-16 tube Option:7.50-16 tube, 7.50R16 tube, 8.25R16 tube
Driver’s Cab
Single cab, 45° hydraulically tiltable to the front,2-arm windscreen wiper system with three speeds, adjustable driver’s seat, with heating and ventilating system, interior double sun visor, sunroof, radio and USB interface, safety belts, adjustable steering wheel, horn.
Electrics
Operating voltage:24 V, negative grounded
Instrument Panel
Active check central controller with indicators, with this integral instrument the daily manual checks on the vehicle and combined indicators of compressed air pressure, coolant temperature, engine oil pressure.
Dimensions in mm
Overall dimension(L x W x H mm) 6995×2180×2450 Body size 5150×2050×550
Weight in kg
Dead weight (kg) 3500 Load weight(kg) 7000 Gross vehicle weight (kg) 10500
Performance
Maximum driving speed(km/h) 95 Maximum grade ability(%) 30 Minimum ground clearance(mm) 210 Minimum turning circle(m) 15.5 Fuel consumption(1/100km) 14.5
Product Advantages
sinotruk howo light cargo truck-5
Intelligent Configuration
The wide-body cab is equipped with mechanical shock-absorbing seats, digital instrument panel and reversing radar, which is comfortable and convenient to operate.
Air brake system is standard, and ABS anti-lock function is optional for some models to ensure the stability of emergency braking.
sinotruk howo light cargo truck-6
Power system
Equipped with 110-120 hp diesel engine (some models support new energy version), matched with 5-speed or 6-speed manual transmission, stable power output.
Adopting 4X2 drive form, with short wheelbase (about 3-4 meters) and small turning radius, it is suitable for flexible steering on narrow roads.
sinotruk howo light cargo truck-7
Environmental protection and low noise
The new energy version achieves zero emission, and the diesel model meets the National VI standard, reducing environmental pollution.
Optimized engine sound insulation technology, running noise is lower than the industry average.
sinotruk howo light cargo truck-8
Economical and efficient
Outstanding fuel economy, with energy costs as low as $1 per 150 kilometers for the new energy version, significantly reducing operating expenses.
Modularized design simplifies the maintenance process, with high commonality of parts and components, resulting in low maintenance costs.
sinotruk howo light cargo truck-9
Bodywork
The load range is 5-10 tons, and the length of the cargo box is optional (4.2m to 6.2m), which is suitable for diversified cargo loading needs.
Lightweight carbon steel frame and split mirrors reduce blind spots and improve driving safety.
Product Applications
sinotruk howo light cargo truck-3
Sinotruk Howo Light Cargo Truck
sinotruk howo light cargo truck-2
Sinotruk Howo Light Cargo Truck
sinotruk howo light cargo truck-1
Sinotruk Howo Light Cargo Truck
